El VLT® Micro Drive es un convertidor de frecuencia de aplicación general que permite controlar motores de CA de hasta
22 kW.
Puede configurarse para funcionar a la perfección incluso en complejas aplicaciones. Unos 100 parámetros configurables
permiten optimizar el rendimiento energético y el funcionamiento del convertidor. Es la solución ideal para: Aplicaciones
generales, Dispositivos industriales, Aplicaciones HVAC y Fabricantes de equipos.
380 VAC Trifásico IP 20 Barnizados
| Códigos | Nº de Parte | Modelo | Potencia | Características |
|---|---|---|---|---|
| 1002662 | 131B8889 | FC-202-PK75 | 0,75/1,0 | 380 VAC/2,4A |
| 1002663 | 131F0650 | FC-202-P1K5 | 1,5/2,0 | 380 VAC/4,1A |
| 1002664 | 131B8907 | FC-202-P2K2 | 2,2/3,0 | 380 VAC/5,6A |
| 1002665 | 131B8915 | FC-202-P3K0 | 3,0/4,0 | 380 VAC/7,2A |
| 1002666 | 131B8934 | FC-202-P4K0 | 4,0/5,5 | 380 VAC/10A |
| 1002667 | 131B8944 | FC-202-P5K5 | 5,5/7,5 | 380 VAC/13A |
| 1002668 | 131F8954 | FC-202-P7K5 | 7,5/10 | 380 VAC/16A |
| 1002669 | 131F6638 | FC-202-P11K0 | 11/15 | 380 VAC/24A |
| 1002670 | 131F6642 | FC-202-P15K0 | 15/20 | 380 VAC/32A |
| 1002671 | 131F6646 | FC-202-P18K5 | 18,5/25 | 380 VAC/37,5A |
| 1002672 | 131F6766 | FC-202-P22K0 | 22/30 | 380 VAC/44A |
| 1002673 | 131F6771 | FC-202-P30K0 | 30/40 | 380 VAC/61A |
| 1002674 | 131F6776 | FC-202-P37K0 | 37/50 | 380 VAC/73A |
| 1002675 | 131F6651 | FC-202-P45K0 | 45/60 | 380 VAC/90A |
| 1002676 | 131F6655 | FC-202-P55K0 | 55/75 | 380 VAC/106A |
| 1002677 | 131F6659 | FC-202-P75K0 | 75/100 | 380 VAC/147A |
| 1002678 | 131F6664 | FC-202-P90K0 | 90/125 | 380 VAC/177A |
| 1002628 | 131B0145 | FC-302-PK75 | 0,75/1,0 | 380 VAC/2,4A |
| 1002629 | 131B0147 | FC-302-P1K5 | 1,5/2,0 | 380 VAC/4,1A |
| 1002630 | 131B0148 | FC-302-P2K2 | 2,2/3,0 | 380 VAC/5,6A |
| 1002631 | 131B0149 | FC-302-P3K0 | 3,0/4,0 | 380 VAC/7,2A |
| 1002656 | 131B0150 | FC-302-P4K0 | 4,0/5,5 | 380 VAC/10A |
| 1002657 | 131B0151 | FC-302-P5K5 | 5,5/7,5 | 380 VAC/13A |
| 1001403 | 131B0152 | FC-302-P7K5 | 7,5/10 | 380 VAC/16A |
| 1001404 | 131F8139 | FC-302-P11K0 | 11/15 | 380 VAC/24A |
| 1002632 | 131F8140 | FC-302-P15K0 | 15/20 | 380 VAC/32A |
| 1002633 | 131H4224 | FC-302-P18K5 | 18,5/25 | 380 VAC/ 37,5A |
| 1002634 | 131H1601 | FC-302-P22K0 | 22/30 | 380 VAC/44A |
| 1002635 | 131H1595 | FC-302-P30K0 | 30/40 | 380 VAC/61A |
| 1002636 | 131H1593 | FC-302-P37K0 | 37/50 | 380 VAC/73A |
| 1002637 | 131H1591 | FC-302-P45K0 | 45/60 | 380 VAC/90A |
| 1002638 | 131H1596 | FC-302-P55K0 | 55/75 | 380 VAC/106A |
| 1002639 | 131H2243 | FC-302-P75K0 | 75/100 | 380 VAC/147A |
| 1002641 | 131H1826 | FC-302-P90K0 | 90/125 | 380 VAC/177A |
