Características
Parada de seguridad, Control en cascada hasta 6 bombas con tarjeta extendida, Deteccion de bomba seca, Alternaciones de motores,
Programación por software via USB MCT 10, Comunicación modbus (opcional Profibus DP, Devicenet, Ethernet ), Funcion final de
curva de bomba detecta roturas y fuga, Control inteligente (tipo PLC), Placa barnizada para entornos agresivos (IEC 721-3-3).
380 VAC Trifásico IP 20 No barnizados
| Códigos | Nº de Parte | Modelo | P.Kw/Hp | Características |
|---|---|---|---|---|
| 1005495 | 131B8886 | FC-202- PK75 | 0,75/1,0 | 380 VAC/ 2,4A |
| 1005496 | 131B8649 | FC-202- P1K5 | 1,5/2,0 | 380 VAC/ 4,1A |
| 1005497 | 131B8903 | FC-202- P2K2 | 2,2/3,0 | 380 VAC/ 5,6A |
| 1005498 | 131B8912 | FC-202- P3K0 | 3,0/4,0 | 380 VAC/ 7,2A |
| 1005499 | 131B8920 | FC-202- P4K0 | 4,0/5,5 | 380 VAC/ 10A |
| 1005500 | 131B8940 | FC-202- P5K5 | 5,5/7,5 | 380 VAC/ 13A |
| 1005501 | 131B8650 | FC-202- P7K5 | 7,5/10 | 380 VAC/ 16A |
| 1005502 | 131F6637 | FC-202- P11K0 | 11/15 | 380 VAC/ 24A |
| 1005503 | 131F6641 | FC-202- P15K0 | 15/20 | 380 VAC/ 32A |
| 1005504 | 131F6645 | FC-202- P18K5 | 18,5/25 | 380 VAC/ 37,5A |
| 1004149 | 131F6764 | FC-202- P22K0 | 22/30 | 380 VAC/ 44A |
| 1005506 | 131F6770 | FC-202- P30K0 | 30/40 | 380 VAC/ 61A |
| 1005507 | 131F6775 | FC-202- P37K0 | 37/50 | 380 VAC/ 73A |
| 1005508 | 131F6650 | FC-202- P45K0 | 45/60 | 380 VAC/ 90A |
| 1005509 | 131F6654 | FC-202- P55K0 | 55/75 | 380 VAC/ 106A |
| 1005510 | 131F6658 | FC-202- P75K0 | 75/100 | 380 VAC/ 147A |
| 1005511 | 131F6663 | FC-202- P90K0 | 90/125 | 380 VAC/ 177A |
380 VAC Trifasico IP 20 Barnizados
| Códigos | Nº de Parte | Modelo | P.Kw/Hp | Características |
|---|---|---|---|---|
| 1002662 | 131B8889 | FC-202- PK75 | 0,75/1,0 | 380 VAC/ 2,4A |
| 1002663 | 131F0650 | FC-202- PK75 | 1,5/2,0 | 380 VAC/ 4,1A |
| 1002664 | 131B8907 | FC-202- P2K2 | 2,2/3,0 | 380 VAC/ 5,6A |
| 1002665 | 131B8915 | FC-202- P3K0 | 3,0/4,0 | 380 VAC/ 7,2A |
| 1002666 | 131B8934 | FC-202- P4K0 | 4,0/5,5 | 380 VAC/ 10A |
| 1002667 | 131B8944 | FC-202- P5K5 | 5,5/7,5 | 380 VAC/ 13A |
| 1002668 | 131F8954 | FC-202- P7K5 | 7,5/10 | 380 VAC/ 16A |
| 1002669 | 131F6638 | FC-202- P11K0 | 11/15 | 380 VAC/ 24A |
| 1002670 | 131F6642 | FC-202- P15K0 | 15/20 | 380 VAC/ 32A |
| 1002671 | 131F6646 | FC-202- P18K5 | 18,5/25 | 380 VAC/ 37,5A |
| 1002672 | 131F6766 | FC-202- P22K0 | 22/30 | 380 VAC/ 44A |
| 1002673 | 131F6771 | FC-202- P30K0 | 30/40 | 380 VAC/ 61A |
| 1002674 | 131F6776 | FC-202- P37K0 | 37/50 | 380 VAC/ 73A |
| 1002675 | 131F6651 | FC-202- P45K0 | 45/60 | 380 VAC/ 90A |
| 1002676 | 131F6655 | FC-202- P55K0 | 55/75 | 380 VAC/ 106A |
| 1002677 | 131F6659 | FC-202- P75K0 | 75/100 | 380 VAC/ 147A |
| 1002678 | 131F6664/td> | FC-202- P90K0 | 90/125 | 380 VAC/ 177A |
380 VAC trifasico IP55 Barnizado
| Códigos | Nº de Parte | Modelo | P.Kw/Hp | Características | |
|---|---|---|---|---|---|
| 01002679 | 1002679 | 131F3939 | FC-202- PK75 | 0,75/1,0 | 380 VAC/ 2,4A |
| 01002680 | 1002680 | 131F3951 | FC-202- P1K5 | 1,5/2,0 | 380 VAC/ 4,1A |
| 01002681 | 1002681 | 131F3952 | FC-202- P2K2 | 2,2/3,0 | 380 VAC/ 5,6A |
| 01002682 | 1002682 | 131F3961 | FC-202- P3K0 | 3,0/4,0 | 380 VAC/ 7,2A |
| 01002683 | 1002683 | 131F3962 | FC-202- P4K0 | 4,0/5,5 | 380 VAC/ 10A |
| 01002684 | 1002684 | 131F3971 | FC-202- P5K5 | 5,5/7,5 | 380 VAC/ 13A |
| 01002685 | 1002685 | 131F3972 | FC-202- P7K5 | 7,5/10,0 | 380 VAC/ 16A |
| 01002686 | 1002686 | 131F3979 | FC-202- P11K0 | 11,0/15,0 | 380 VAC/ 24A |
| 01002687 | 1002687 | 131F3980 | FC-202- P15K0 | 15,0/20,0 | 380 VAC/ 32A |
| 01002688 | 1002688 | 131F3987 | FC-202- P18K5 | 18,5/25,0 | 380 VAC/ 37,5A |
| 01002689 | 1002689 | 131F3988 | FC-202- P22K0 | 22,0/30,0 | 380 VAC/ 44A |
| 01002690 | 1002690 | 131F3997 | FC-202- P30K0 | 30,0/40,0 | 380 VAC/ 61A |
| 01002691 | 1002691 | 131F3998 | FC-202- P37K0 | 37,0/50,0 | 380 VAC/ 73A |
| 01002692 | 1002692 | 131F4009 | FC-202- P45K0 | 45,0/60,0 | 380 VAC/ 90A |
| 01002693 | 1002693 | 131F4010 | FC-202- P55K0 | 55,0/75,0 | 380 VAC/ 106A |
| 01002694 | 1002694 | 131F4021 | FC-202- P75K0 | 75,0/100,0 | 380 VAC/ 147A |
| 01002695 | 1002695 | 131F4022 | FC-202- P90K0 | 90,0/125,0 | 380 VAC/ 177A |
Accesorios
| Códigos | Nº de Parte | Descripción |
|---|---|---|
| 1002696 | 130B1117 | Panel Mounting Kit FC-202 |
| 1002697 | 130B1200 | Modulo Profibus barnizado |
| 1001407 | 130B1100 | Modulo Profibus no barnizado |
| 1002698 | 130B1202 | Modulo Devicenet barnizado |
| 1002699 | 130B1219 | Modulo Ethernet barnizado |
| 1004644 | 130B1119 | Modulo Ethernet no barnizado |
| 130B1235 | Modulo Profinet barnizado | |
| 130B1135 | Modulo Profinet no barnizado | |
| 1002700 | 130B1228 | Control cascada Extendido, barnizado FC-202 |
| 1003074 | 130B1154 | Control cascada Advanced, no barnizado |
| 1001405 | 130B1107 | Display gráfico |
