El VLT® Micro Drive es un convertidor de frecuencia de aplicación general que permite controlar motores de CA de hasta
22 kW.
Puede configurarse para funcionar a la perfección incluso en complejas aplicaciones. Unos 100 parámetros configurables
permiten optimizar el rendimiento energético y el funcionamiento del convertidor. Es la solución ideal para: Aplicaciones
generales, Dispositivos industriales, Aplicaciones HVAC y Fabricantes de equipos.
380 VAC Trifásico IP 55 Barnizados
| SAP | Códigos | Nº de Parte | Modelo | Potencia kW/HP | Características |
|---|---|---|---|---|---|
| 01002679 | 1002679 | 131F3939 | FC-202-PK75 | 0,75/1,0 | 380 VAC/2,4A |
| 01002680 | 1002680 | 131F3951 | FC-202-P1K5 | 1,5/2,0 | 380 VAC/4,1A |
| 01002681 | 1002681 | 131F3952 | FC-202-P2K2 | 2,2/3,0 | 380 VAC/5,6A |
| 01002682 | 1002682 | 131F3961 | FC-202-P3K0 | 3,0/4,0 | 380 VAC/7,2A |
| 01002683 | 1002683 | 131F3962 | FC-202-P4K0 | 4,0/5,5 | 380 VAC/10A |
| 01002684 | 1002684 | 131F3971 | FC-202-P5K5 | 5,5/7,5 | 380 VAC/13A |
| 01002685 | 1002685 | 131F3972 | FC-202-P7K5 | 7,5/10,0 | 380 VAC/16A |
| 01002686 | 1002686 | 131F3979 | FC-202-P11K0 | 11,0/15,0 | 380 VAC/24A |
| 01002687 | 1002687 | 131F3980 | FC-202-P15K0 | 15,0/20,0 | 380 VAC/32A |
| 01002688 | 1002688 | 131F3987 | FC-202-P18K5 | 18,5/25,0 | 380 VAC/37,5A |
| 01002689 | 1002689 | 131F3988 | FC-202-P22K0 | 22,0/30,0 | 380 VAC/44A |
| 01002690 | 1002690 | 131F3997 | FC-202-P30K0 | 30,0/40,0 | 380 VAC/61A |
| 01002691 | 1002691 | 131F3998 | FC-202-P37K0 | 37,0/50,0 | 380 VAC/73A |
| 01002692 | 1002692 | 131F4009 | FC-202-P45K0 | 45,0/60,0 | 380 VAC/90A |
| 01002693 | 1002693 | 131F4010 | FC-202-P55K0 | 55,0/75,0 | 380 VAC/106A |
| 01002694 | 1002694 | 131F4021 | FC-202-P75K0 | 75,0/100,0 | 380 VAC/147A |
| 01002695 | 1002695 | 131F4022 | FC-202-P90K0 | 90,0/125,0 | 380 VAC/177A | 1002642 | 131B6776 | FC-302-PK75 | 0,75/1,0 | 380 VAC/2,4A |
| 1002643 | 131B6778 | FC-302-P1K5 | 1,5/2,0 | 380 VAC/4,1A | |
| 1002644 | 131B4652 | FC-302-P2K2 | 2,2/3,0 | 380 VAC/5,6A | |
| 1002645 | 131B6428 | FC-302-P3K0 | 3,0/4,0 | 380 VAC/7,2A | |
| 1002646 | 131B6426 | FC-302-P4K0 | 4,0/5,5 | 380 VAC/10A | |
| 1002647 | 131B4323 | FC-302-P5K5 | 5,5/7,5 | 380 VAC/13A | |
| 1002648 | 131B3465 | FC-302-P7K5 | 7,5/10 | 380 VAC/16A | |
| 1002649 | 131B1647 | FC-302-P11K0 | 11/15 | 380 VAC/24A | |
| 1002650 | 131B1788 | FC-302-P15K0 | 15/20 | 380 VAC/32A | |
| 1002651 | 131B2082 | FC-302-P18K5 | 18,5/25 | 380 VAC/37,5A | |
| 1002652 | 131B2296 | FC-302-P22K0 | 22/30 | 380 VAC/44A | |
| 1002653 | 131B6806 | FC-302-P30K0 | 30/40 | 380 VAC/61A | |
| 1002658 | 131B6807 | FC-302-P37K0 | 37/50 | 380 VAC/73A | |
| 1002659 | 131F1356 | FC-302-P55K0 | 55/75 | 380 VAC/106A | |
| 1002660 | 131F1359 | FC-302-P75K0 | 75/100 | 380 VAC/147A | |
| 1002661 | 131F1963 | FC-302-P90K0 | 90/125 | 380 VAC/177A |
ACCESORIOS
| Códigos | Nº de Parte | Descripción |
|---|---|---|
| 1002696 | 130B1117 | Panel Mounting Kit FC-202 |
| 1002697 | 130B1200 | Modulo Profibus barnizado |
| 1001407 | 130B1100 | Modulo Profibus no barnizado |
| 1002698 | 130B1202 | Modulo Devicenet barnizado |
| 1002699 | 130B1219 | Modulo Ethernet barnizado |
| 1004644 | 130B1119 | Modulo Ethernet no barnizado |
| 130B1235 | Modulo Profinet barnizado | |
| 130B1135 | Modulo Profinet no barnizado | |
| 1002700 | 130B1228 | Control cascada Extendido, barnizado FC-202 |
| 1003074 | 130B1154 | Control cascada Advanced, no barnizado |
| 1001405 | 130B1107 | Display gráfico |
